How Does a Wet Painting Booth Work?

June 17, 2020

If your work entails painting on a large scale, you may have considered using a wet paint booth. These powerful chambers create an efficient, safe way to paint or finish products. By providing clean, particulate-free air, you can achieve excellent results and stay a step above the competition.

So how does a paint booth work, and what all does it do for you? We’ve got answers to those questions and more down below.

What Is a Paint Booth?

A paint booth is a large, contained environment equipped with exhaust fans and filters to make commercial spray painting safer and cleaner. It improves results by altering air pressure to blow contaminants out of the container and clear out overspray from the paint sprayers. As it does this, fresh, clean air is consistently pushed into the booth.

There are a few primary components to a paint spray booth, some of which will determine your paint booth’s airflow requirements.

  • Exhaust fan: The exhaust fan is what draws air out of the booth. It will pull out the air that is contaminated with overspray and particles. As that air enters the exhaust, a filter grabs onto those excess particles and catches the contaminants. Exhaust fans and filters help organizations abide by environmental regulations that require them to reduce air pollutants from their painting processes.
  • Air replacement fan: As all that contaminated air leaves, it needs to be replaced. With mechanical air replacement methods, new, fresh air gets pushed into the booth to keep the pressure at a consistent level.
  • Pit: Some models of paint booths will have a pit. In a downdraft model, the air flows down around the object and into a pit, which is an open space beneath the object covered with a grate, so air can still flow through. Typically, the pit is excavated out of the building’s infrastructure or the entire booth is raised up on a platform. Non-pitted models will vary significantly in how air flows through, but we’ll talk more about that later.

The configuration of these elements will influence the direction of airflow and how your paint booth ventilation works. Some models, like downdraft booths, will envelop the object and push air down beneath it. Other designs can move the air horizontally or in varying configurations.

One concern when working with paint booths is flammability. Many paints release flammable chemicals that can pose a danger to employees and your facility. To combat this, the Occupational Safety and Health Administration (OSHA) requires you to meet certain standards for sprinkler systems and your filters.

What Are the Benefits of a Paint Booth?

A paint booth is a significant component of many industrial manufacturing plants. It can:

  • Improve results: A paint booth pulls contaminants out, helping you to achieve a smoother, cleaner coating. Some designs can even blow paint over uncoated areas to create a more uniform finish.
  • Abide by regulations: You can play nice with the Environmental Protection Agency and meet or exceed their requirements regarding the dangerous chemicals involved in paint spraying. Plus, it can keep your employees safer by limiting their exposure.
  • Reduce costs: With the right paint spray booth, you can lower the costs required to operate it. Improved coating quality can also minimize material and labor costs. You may need to use fewer layers and touch-ups.

A paint booth can offer the most professional-grade paint jobs possible. If you can’t risk subpar coverage, then a paint booth is the way to go.

how does a paint booth work

How Does a Paint Booth Work?

A paint booth works by manipulating the principles of negative and positive air pressure. Spray painting booth ventilation relies on the balance of the exhaust fan and the air replacement fan.

  • If just the exhaust fan is on, the booth takes on negative pressure, since more air is being removed than pushed in. If the door opens, it will try to pull in as much air as it can from the outside, yanking in dirt and debris along with it.
  • If just the replenishing fan is on, you’ll get positive air pressure in the booth, and it will try to push that air outward when the door is open. Contaminants and debris will get swept away from it, keeping the inside cleaner.

To create an effective working environment, these two fans work together to remove and replace air at comparable rates. With a slightly positive booth, you can keep dirt and debris out even as the door is opened. This method of keeping negative particles out is effective at keeping rooms clean — so effective, in fact, that you can find it employed in healthcare spaces.

Two factors can significantly affect the success of a paint booth — your filters and volume changes. If a filter gets filled up completely with overspray, the exhaust fan will struggle to pull air through it. Without an exit point, the booth can become overpressurized.

As for the volume, you simply have to keep in mind that adding an item into the booth will reduce the amount of space that needs to be pressurized. If you pump the same amount of air into a filled booth as you would when it was empty, you’ll overpressurize it.

How Can Finishing Systems Help?

Finishing Systems has a variety of booth configurations to meet the needs of businesses of all types. We offer:

  • Downdraft paint booths: A downdraft booth is the best approach for removing overspray. The air moves down and around the object and into a pit beneath it, where the exhaust fans go to work. Downdraft can create a better paint job, as it pulls excess paint down and away from the part.
  • Side-downdraft paint booths: In this kind of booth, fresh air comes down from the ceiling and exits at the side-wall exhausts. It still offers airflow that moves mostly downward in an environment where a pit is not feasible.
  • Semi-downdraft paint booths: Instead of pulling air directly beneath the object being painted, a semi-downdraft booth has exhaust vents in the corners. This solution also works for locations without a pit.
  • Crossdraft paint booths: A crossdraft paint booth uses horizontal airflow from the front to the back. This is one of the lowest-cost options for organizations that can’t excavate a pit.

With each of these options, you have choices for control panels, air heaters, industrial fan assemblies, lighting options and observation windows. We can even provide custom designs if none of those meet your needs.

wet paint booths from finishing systems



Wet Paint Booths From Finishing Systems

Another benefit that you get when you work with Finishing Systems is the world-class service that we offer. For every piece of equipment from us, our team is ready to help with everything from design and installation to training and service. Clients from a wide variety of industries trust Finishing Systems to bring safe and efficient paint booths to their manufacturing processes.

Whether you need quality paint coatings or a better way to control chemical emissions, paint spray booths can help. For more information on implementing these solutions in your plant, reach out to us today.
